LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale

LXSHOW LASER LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine is a product specially designed for tube metal laser cutting machine. It has stronger cutting ability and higher cutting precision. Do you want to know more about it? The product details page below can help you.

Rating:

Customer Service Hotline

+8613256742787

  • Product Description

  • Video

  • Parameters

  • Samples

  • How Order

LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale

LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale

LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


The Segmented Rectangle Laser Tube Welded Bed

Good rigidity, high precision, no deformation during the life cycle;

Welded aluminum collet board, formed through high precision process. Good weight and good dynamic performance


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


Pneumatic Chunk Clamping Design

It adopts an pneumatic clamp design on both sides and it can modulate the center automatically.The diagonal adjustable range is 20-220mm(320/350,Φ20-Φ500 is optional)


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


Fractional Automatic Support Installation

It employs intelligent tube support design, which can solve the deformation

problems in the process of long tube cutting


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


Professional Clamp Design

Automatic pneumatic chuck, adjustable and stable, clamping range is wider and clamping force is larger. Non - destructive pipe clamping, fast automatic centering and clamping pipe, performance is more stable. The chuck size is smaller, rotation inertia is low, and dynamic performance is strong. Self-centering pneumatic chuck, gear transmission mode, higher transmission efficiency, long working life and high work reliability


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


Intelligent Auto Focus

l Efficient Cooling

Both the collimating lens and the focusing lens group are cooling structures, and the cooling air nozzle is added at the same time, which effectively protects the nozzle and ceramic body and prolongs the working time.

l Chasing Aperture

Through the aperture of 35 mm, the interference of stray light is effectively reduced.

l Auto focus

Auto focus, reduce human interference, focus speed 10m/min, repeatability 50 microns 25mm carbon steel plate pre-punching time <3s@3000w, greatly improving cutting efficiency.


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine for Sale


The Absolute Value Servo Motor

System is equipped with servo motor, boot to homework, do not need to return to zero operation, power outages, a key recovery cutting operation


LX123TX Best Three Chuck heavy-duty Laser Metal Pipe Cutting Machine


LX123H(12)TIV Four Chuck Fiber Laser Cutting Metal Tube Pipe Machine Application:

Application Materials:

Fiber Laser Metal Cutting Machine is suitable for metal cutting like Stainless Steel Tube, Mild Steel Tube, Carbon Steel Tube, Alloy Steel Tube, Spring steel Tube, Iron Pipe, Galvanized Steel Tube, Aluminum Pipe, Copper Tube, Brass Tube, Bronze Pipe,  Titanium Pipe, Metal Tube, Metal Pipe, etc.

Application Industries:

Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Tube Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.
