LX6025H

Home >> Fiber Laser Cutter >> High Power Laser Cutting Machine >> LX6025H

LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW

LXSHOW LASER LX6025H is a product specially designed for sheet metal laser cutting machine. It has stronger cutting ability and higher cutting precision. Do you want to know more about it? The product details page below can help you.

Rating:

Customer Service Hotline

+8613256742787

  • Product Description

  • Parameters

  • Samples

  • How Order

LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW

LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW

LX3015H Full Cover Exchange Table Metal Fiber Laser Cutting Machine 2000W 4000W 6000W 8000W


Exchange Table

It adopts an up and down exchange platform;

The converter is responsible for controlling the exchanging motor;

The machine is able to finish the platform exchanging within 15s.


LX3015H Full Cover Exchange Table Metal Fiber Laser Cutting Machine 2000W 4000W 6000W 8000W


Aviation Aluminum Gantry

It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.


LX3015H Full Cover Exchange Table Metal Fiber Laser Cutting Machine 2000W 4000W 6000W 8000W


Intelligent Autofocus

The high efficiency cooling:
Collimating lens and focus lens group are cooling structure, increase cooling airflow nozzle at the same time, the effective protection of nozzle, the ceramic body, prolonged work time.


Chase the light aperture:
Through the pore diameter of 35 mm, effectively reduce the stray light interference, ensuring cutting quality and service life.

Automatic focus:
Automatic focus, reduce human intervention, focusing speed 10 m/min, repeat accuracy of 50 microns.


High speed cutting:
25 mm carbon steel sheet pre punch time < 3 s @ 3000 w, greatly improve cutting efficiency.


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW


Transmission And Precision

LXSHOW fiber laser cutting machine is equipped with German Atlanta rack, Japanese Yaskawa motor and Taiwan Hiwin Rails. The positioning accuracy of the machine tool can be 0.02mm and the cutting acceleration is 1.5G. The working life is up to more than 15 years.


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW


Bochu System

Easy to operate evenby green hands, Match with 20000 process data on its graphical programming interface, Compatible with multile graphic files, incl. DXF DWG, PLT and NC code, Improve stock layout and material utilization by 20% and 9.5% by its built-in nesting software, with no limit of quantity of spare parts, Support language: English, Spanish, Portuguese, Russian, German, French, Italian, Japanese, Korean, Dutch, Czech, Simplified Chinese, traditional Chinese.


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW


Safety and Environment Protection

•  With a fully enclosed design;

•  The observation window adopts an European CE Standard laser protective glass;

•  The smoke produced by cutting can be filtrated inside, it's non-polluting and environmentally friendly;


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine 4KW 6KW 8KW 12KW


Monitoring system

Real-time observe the machine running through the panel


LX3015H Full Cover Exchange Table Metal Fiber Laser Cutting Machine 2000W 4000W 6000W 8000W


LX6025H Full Cover Exchange Table Fiber Laser Sheet Metal Cutting Machine Application:

Application Materials:

Fiber Laser Metal Cutting Machine is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, etc.

Application Industries:

Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.


LX3015H Full Cover Exchange Table Metal Fiber Laser Cutting Machine 2000W 4000W 6000W 8000W
